Upgraded 768A-845 Furnace Hot Surface Ignitor Replacement Compatible with Emerson White-Rodgers Trane Silicon Nitride Ignitor, 768A-845 Replace 768A-5 IGN00104 X13130524010 B340970P01

Additional Details from the Manufacturer

This item information is coming from the manufacturer. Some of the details may vary from the Nellis Auction listing. Please check the Quality Rating and Notes for information specific to this listing

More features

• 【Product Size】768A - 845 Silicon Nitride Hot Surface Igniter | Specs: 80VAC, 50/60Hz, cold resistance 15-47 Ohms @25°C, operating current 3.5 - 5.0 Amp. 768A - 845 hot surface igniter plug specifications: 2 - terminal AMP; 0.084" female sockets. Wire specifications: white high - temperature Teflon coated wires, wire length: 5 in; insulation grade: 250°C. Dimensions of 768A-845 hot surface ignition: 3*1.25*0.35 in
• 【Installation Notes】768A-845 igniter is extremely fragile and should be handled with care during installation. 768A-845 is prone to invisible minor damage during transportation and installation, which may render it inoperable. Measure resistance before use; it should be 25-47 Ohms (25°C). Replace promptly if any abnormalities are found
• 【Premium Material】768A-845 furnace heater igniter is made of high-quality silicon nitride. Each unit undergoes strict inspection, with an average ignition count of 100,000 times. Upgraded 768A-845 ignition pin ensures faster ignition, along with enhanced safety and reliability. 768A - 845 rapidly heats up to 800 - 1000°C ignition temperature in 10 - 17 seconds after power - on.
• 【Compatible Models】768A-845 gas furnace hot surface igniter compatible with Emerson White-Rodgers Trane, 768A-845 silicon furnace nitride igniter replace 768A-5 IGN00104 X13130524010 B340970P01 ignitor
• 【Fix Symptoms】1.Broken igniter causes ignition failure. 2.Slow or repeated ignition required. 3.Cracked igniter poses safety risk. If you encounter any quality concerns. We conduct strict quality checks and continuously optimize our products. Thank you for your support! This will be very important for us
