AMTAST Digital Window Tint Meter Solar Film Transmission Meter with Automatic Calibration 7-in-1 UV IR Rejection Meter for UV, Visible Light, IR 940nm, IR 1400nm, Full IR, TSER, SHGC (Model AMT537)

7 IN 1 Window Tint Meter for UV, Visible Light, IR 940nm, IR 1400nm, Full IR, TSER, SHGC Product Information: 1. UV Peak Wavelength: 365nm 2. Visible Light Peak Wavelength: 380nm ~ 760nm, CIE function of photopic vision 3. IR Peak Wavelength: Peak wavelength 940nm, 1400nm and Full IR 4. Solar Heat Gain Coefficient: SHGC (0.000 ~ 1.000) 5. Total Solar Energy Rejection TSER: 0.0% ~ 100%) 6. Resolution: 0.1% 7. Accuracy: ±2% (colorless uniform light-transmitting material) 8. Maximum Sample Thickness: 0.8mm 9. Display: 240*240 dot matrix TFT color screen 10. Weight: about 70g 11. Size: 101mm x 52mm x 25.5mm 12. Power Supply: 4*AAA alkaline battery Product Features: 1. 7 IN 1 Window Tint Meter – The compact window tint meter is designed to measure the infrared and ultraviolet rejection, visible light transmittance, Total Solar Energy Rejection (TSER), and Solar Heat Gain Coefficient (SHGC) of various film types, including sun control and safety films. It's ideal for solar film demonstrations, manufacturing, and quality control applications. 2. High-Resolution Display – The glass tint meter features a TFT color screen that displays ultraviolet and infrared rejection rates as well as visible light transmittance. The data is presented using colorful progress bars, allowing for easy and intuitive readings. The screen can rotate 180°, making it convenient to view from any angle and offering multiple display configurations for user customization. 3. Data Hold Function – The light transmitter meter comes with a data hold feature, allowing users to freeze the displayed data on the screen. Even after removing the film, the measurement results remain visible, making it easy to review the data. The meter offers different display modes such as rejection rate, transmittance, or single transmittance view, which can be tailored to your preferences. 4. Real-Time Calibration – The solar film meter is equipped with real-time dynamic calibration. When no material is placed in the test slot, the device automatically calibrates to ensure accurate measurements, providing precise results for every test. 5. Advanced Solar Heat Performance Evaluation – The tint solar film car transmission meter allows you to evaluate important parameters such as SHGC and TSER, giving you in-depth insights into a film’s thermal insulation performance. This makes the meter a valuable tool for assessing solar films’ effectiveness in reducing heat gain.
