ANMBEST 13S 48V 35A PCB BMS Protection Board Li-ion Lithium Battery Charger Lipo Cell Module with Balance for Battery Cell Pack

Specifications: Color: Silver + Green Material: metal + PCB Continuous Discharge Current: 35A Momentary Discharge Current: 100A Charge Voltage: 54.6V Charge Current: 8A(Max.) Overcharge Protection Overcharge Detection Voltage: 4.28±0.05V Overcharge Protection Delay: 100mS Overcharge Cancel Voltage: 4.08±0.05V Over-discharge Protection Over-discharge Detection Voltage: 2.55±0.08V Over-discharge Detection Delay: 50mS Over-discharge Cancel Voltage: 3.0±0.1V Cell balance voltage: 4.2±0.025V Cell balance Cancel voltage: 4.2±0.05V Cell balance current: 60±5mA Overcurrent Protection Overcurrent Detection Voltage: 150mV Overcurrent Detection Delay: 15mS Overcurrent Protection Current: 120±5A Protection Cancel Condition: Disconnect Load Short Circuit Protection Short Circuit Protection Condition: Outside Load Short Circuit Short Circuit Detection Delay: 200uS Protection Cancel Condition: Disconnect Load Internal Resistance Main Circuit Conduction Internal Resistance: less than 15mΩ Self Power Consumption Working Current: less than 50uA Sleeping Current(Battery Over-discharge): less than 10uA Operating Temperature: -30℃~+80℃Weight: 52g Size:69 mm×51.5 mm×10 mm/ 2.72″ ×2.03″×0.39″ Attention: Strictly according to the diagram wiring, Otherwise it will cause damage to the chip. Do not mix the good battery and poor battery to use. The internal resistance of battery capacity are closer will be better. Package included: 1x 13S 35A lithium Battery Protection Board with Balanced
