AURSINC Radioberry Preamp Board V2, A Addition to Turn The Radioberry into a Small QRP Radio, Output 1.5W-3W for HF Power Ampfier (10W-100W PA), for Raspberry pi 4,4b

Features

• This Radioberry Preamp Board V2 is a nice addition to turn the radioberry into a small QRP radio. The design is based on all the amazing work of Hermes Lite 2 Group. Reference Link: mmdvm .club/index .php/archives/305/
• [Technical Specs] Power in : 8.5V. RF range: 1mhz-50mhz. HF Power in: Tx from radioberry. HF Power out: 5W. Output 1.5W-3W for HF Power Ampfier (10W-100W PA). Input SMA, Output SMA
• [Operation] The board (2-layers) must be plugged on top of the radioberry. After the assembly is complete, connect to the computer via the Type C port on the radioberry Juice USB board for setup and control. It is not compatible with Raspberry PI
• [What's Inside] 1x Radioberry Preamp Board; 3x SMA cable (1 for Rx ,1 for Tx,1 for ANT); 1x 8V Battery-powered Wire; 1x Connecting Row Needle; 4x Screw and Nut; 8x Plastic Column
• [HOW to Work] jumbo5566.github .io/pro/rb/2024/04/17/rb016_025 .html
