Aepiraza 031-01267-001A Control Board Compatible with York Coleman 031-01972-000, P031-01267-001, 031-01266-000, 031-01140-702 Furnace Control Board

Additional Details from the Manufacturer

This item information is coming from the manufacturer. Some of the details may vary from the Nellis Auction listing. Please check the Quality Rating and Notes for information specific to this listing

More features

• This Control Board is Designed to Replace Part #s 031-01267-001A, 031-01267-001, 031-01972-000, P031-01267-001, 031-01266-000, 031-01140-702, S1-03101267001, S1-03101972000 & More
• Application: Compatible with Yo-rk Cole-man Lux-aire P031-01267-001 031-01267-001A Furnace Control board
• The S1-33103010000 Control Board is an automatic gas interrupted ignition control. It uses a microprocessor to continuously monitor, analyze, and control the proper operation of the gas burner, inducer, and fan. These controls incorporate system fault analysis for rapid gas flow shut-off. Additionally, they perform automatic ignition retry when a fault correction is sensed
• Input Voltage: 25 VAC 50/60 Hz, Max. Input Current @ 25 VAC:0.45 amp, Valve Re-lay:1.5 amp @ 25 VAC 50/60 Hz 0.6 pf, Ignitor Relay: 6.0 amp @ 120 VAC 50/60 Hz (resistive), nducer Relay: 2.2 FLA–3.5 LRA @ 120 VAC, Circulator Relay: 14.5 FLA–25.0 LRA @ 120 VAC
• High quality is achieved through advanced, microprocessor-based high-precision PCB manufacturing, soldering and assembly technology. When installing and servicing the furnace, be cautious to avoid and control electrostatic discharge
