Blower Fan DC 12V 2W 0.18A,Length 1.97 Inch Height 1.97 Inch Thichness 0.59 Inch Circular Frame DC Brushless Fan,5000 RPM DC Cooling Fan,2.5-2P pin(DC12V5015H12S)

This is a low-power DC blower fan, with high air volume, low noise, long service life and other characteristics, widely used in communication electronics, power and other places need heat dissipation. The basic characteristics are: Modal NO.:PY-5015H12S Operation Voltage Range:DC 5V-13.8V Rated Current:0.18A Power Consumption:1.2W-2.4W Dimension of Fan:50mm X 50 mm X 15 mm,Circular Frame Speed：5000±10％R.P.M Airflow：4.2CFM Air Pressure：11.85mmH2O Noise：37dB(A) Lead Wire：The frame red-black wire is 300±10 mm long, 26AWG, UL certified,the red line positive and black line negative，2.5-2P pin.Circuit is protected when VCC＆GND are exchanged. Frame & Blade：PBT Black , environmentally friendly, fire-resistant in line with the UL94V0 standard Rotating Direction：Counterclockwise Operating temperature/humidity range：-20℃～70℃，35%～85%RH Insulation grade：UL Class A Expect Life：30,000hrs,40℃ 1 Pack: 1 pcs Please do not use the fan in the environment of corros ive gas or liq.For softy's reason, finger guard will be need on the inlet and outlet sides of fan. Do not try to touch or hold the impeller from.
