Buxatina 115V 17GPM Three-Speed Circulator Pump Replacement for Grundfos UPS15-58FC (UPS 15-58 FC) Nonsubmersible Circulation Pump 1/25HP Replace# 59896341

【Compatible With】 Replacement for Grundfos UPS15-58FC (UPS 15-58 FC); Replacement Number: 59896341; Suitable for commercial heating and air-conditioning systems and is also used for central and district heating systems. 【Package List & Specification】 Package Includes: 1 pcs x 115V 17GPM Three-Speed Circulator Pump; 1 set x Mounting Accessories; Materials： Pump housing: Cast iron (EN 1561 EN-GJL-200)； Impeller: Composite (PES+30% GF)； Shaft: Ceramic； Bearing: Carbon Axial； Technical: Speed no: 3 Rated flow: 1.93 m³/h Max flow: 3.9 m³/h Flow Range: 0-17 GPM (Gallons Per Minute); Rated head: 3.19 m Max head: 5.9 m Head Range: 0-19.5 ft; Horse Power: 1/25HP Electrical data Phase: 1; Rated Voltage: 115V; Amperage at Speed 1 : 0.55A; Amperage at Speed 2 : 0.66A; Amperage at Speed 3 : 0.75A; Watts at Speed 1 : 60W; Watts at Speed 2 : 80W; Watts at Speed 3 : 87W; Mains frequency: 60 Hz; Capacitor size - run: 10 µF/180 V Number of poles: 2 Insulation class (IEC 85): F Liquid Pumped liquid: Water; Liquid temperature range: 2~110 °C; Selected liquid temperature: 60 °C Density: 983.2 kg/m³ 【Installation】 Max ambient temperature: 40 °C; Amb. max at 80 dgr C liquid: 80 °C; Max operating pressure: 10 bar (145 Psi); Type of connection: 2-BOLT FLANGE (C.I. Flange); Pipe connection: 2-BOLT FLANGE; Pressure rating for connection: PN 10; Port-to-port length: 166 mm; 【Excellent Performance】 Built-in motor protection for longer life and better performance. Whisper-quiet operation for sound sensitive installations. 【Buy with Confidence】 This 115V 3-Speed Circulator Pump is factory-proven. We will be responsible for dealing with them if the product has any quality problems within 1 year
