CNCTOPBAOS 4 Axis Offline CNC Controller DDCSV4.1

This CNCTOPBAOS 4 Axis Offline CNC Stand Alone Motion Controller features a 7-inch TFT screen with a 1024x600 resolution and 17 operation keys. It utilizes an ARM9 main control chip and an FPGA core algorithm chip. The controller offers differential mode and double pulse mode output signals, with a maximum interpolation pulse output frequency of 500Khz/Axis. It supports 2-4 axis linear interpolation and any 2 axis circular interpolation. The system includes 18 photoelectric isolated digital inputs and 3 photoelectric isolated digital outputs. The spindle can be configured as an Analog spindle (0-10V) or a servo spindle. It supports G code files via USB flash disk and Ethernet communication, with no size limit for G-code files. Power requirements include a 24VDC power supply for the IO Port (minimum 0.5A) and a 24VDC power supply for the controller system (minimum 0.5A).
