CNCTOPBAOS DMA860S Digital Stepper Motor Driver,2.2A-8.2A Single/Double Pulse 16 Subdivisions 20V-110V AC or 20-160V DC Input Driver Controller for Nema23,Nema24,Nema34 Stepper Motor,CNC Machine

Features

• Specifications: Input Voltage: 20-110V AC or 20-160V DC; Output Peak Current: 2.2A-8.2A; Optical isolation differential signal input,the input pulse response frequency can reach up to 300KHz
• 16 types of Subdivision: Users can set 400-51200 within the arbitrary subdivision and rated current within the arbitrary current value,adopts built-in micro-subdivision technology,even in the conditions of low subdivision,also can achieve high subdivision effect,low,medium and high-speed operation is very smooth and ultra-low noise
• Applicable motors: Can drive 4,6,8-wire two-phase stepper motor,suitable for Nema23,Nema24,Nema34 and Nema42 Stepper Motor;Automatic halving of current at rest
• Multi functional: PI control algorithm,with over voltage,undervoltage alarm,phase current overcurrent,motor phase open circuit detection and other functions;Signal input: single ended, pulse+direction, and dual pulse
• Applications: Widely used in various small and medium-sized automated equipment and instruments, e.g: Milling Machine, Engraving Machine, Marking Machines, Cutting Machines, Carving Machines, CNC Router Machines , Automatic Assembly Equipment, etc
