ChongXiao Electric Bike Electric Scooter Intelligent Brushless Square Wave Controller LCD Display 24V 36V 48V 60V 350W 500W Universal XT60

intelligent brushless square wave controller for electric bike/electric scooter/brushless motor not connect hall wires aslo can work voltage：24V/36V/48V/60V universal current：6A-20A number of transistors: 6 rated power：250W-350W all can work 1.low level brake 2.PAS (pedal assist) 3.brake light power 4.hall 5.reverse gear 6.intelligent recognition 7.linear brake（Thumb brake） 8.LCD 9.electric door lock 10.head light/tail light 11.phase line 12.battery how to connect ？ 1.connect the phase line color to color connection 2. connect the battery line(red wire :battery + , black:battery-) 3. connect the controller LCD line,connect electric door lock 4. connect the hall line(if motor without hall line, don't need connect) 5.docking the two intelligent recognition line also call self-learning lines, the wheel will forward or reverse. (1.if wheel forward ,Separate the self-learning line. 2.if wheel reverse, Separate the self-learning line. Docking the self-learning line again，if wheel forward ,Separate the self-learning line. 3.This function allows the controller to intelligently identify the battery voltage and adjust the rotation direction of the motor） 6.other functions can be connected as needed.
