Cole Hersee (1235-BX) 6-Pole Socket with Protective Housing

Normally used with a trailer where limited functionality (taillights, brake lights) is needed. Ideal for boat trailers, or RVs towed by a car on a flatbed trailer. Die cast metal housing. Screw terminals accept up to 12 AWG wire; replaceable interior. Brass split-pin contacts are aligned to assure proper contact and minimal voltage drop. Spring-loaded socket door, plug locks securely into the opening. Wiring codes are identified on the insulator. Two mounting holes on the flange 6.7 millimeter diameter and 74.6 millimeter on centers. Mounts through 34.9 millimeter diameter hole.
