Doinal ND72260 Programmable High Power Electric Motorcycle Controller 80A Current BLDC for 2-3KW Brushless Motor Controller for Electric Dirt Bike Scooter Motor

Features

• [Sine Wave Controller Features]: FarDriver controller is sine wave controller, which is brushless DC controller with self-learning function. It’s HALL VERSION (as default) which suit with hall motors. Generally, it matches well with QS Motors, 1020 Motor, and others, if you want to match with new motor, some parameters should be tested by yourself. It maybe need Program again, and must download the app.
• [Programmable BLDC Controller]: "Built-in Bluetooth" controller, so there is no have bluetooth dongle in the package, You can directly connect BT and the controller within the APP (Please see the user guider, detailed instructions on how to set up.) The Fardrive app is compatible with both Apple and Android. Android users can find out how to download it in the detailed description, while Apple users search for "Fardrive" in the app store.
• [Electric Motorcycle Controller Parameter]: ND72260(KR72260) is 72V 3000W controller with waterproofing grade IP67, suit for 2-3kw Brushless motors Hall. Rated Voltage 72V, the peak voltage is 88V, it suitable for 48-72V , rated power: 3KW, Max DC Current 80A, Phase current 260A, Net Weight 1KG. Please carefully compare whether the size of the product is suitable for your project to avoid installation problems
• [Electric Dirt Bike Upgrade]: All the raw materials are imported, using high-performance Moss tube With the aluminum substrate scheme, the Moss tube is laid on the aluminum substrate and then placed on the PCB board. If the iginition lock is not connected, please connect the "E-Lock" orange wire to the positive pole, otherwise there will be no power.
• Small in size, High efficiency, low temperature rise, small running current With self-learning function, excellent commonality, With flux weakening function.(The product does not contain magnetism) It suit for electric Motorcycle Motor and other type Motors. After our investigation, very few customers will encounter the problem of missing parts. If it happen, please let us know, and we will replace it in time.
