ESP32-S3 1.64inch AMOLED Touch Display Development Board, 280×456 Resolution, 16.7M Color, QSPI Interface, Wi-Fi and BLE-5 Support, Onboard 6-Axis IMU, TF Card Slot, USB, UART, I2C, etc.

Additional Details from the Manufacturer

This item information is coming from the manufacturer. Some of the details may vary from the Nellis Auction listing. Please check the Quality Rating and Notes for information specific to this listing

More features

• ESP32-S3 1.64″ AMOLED touch display development board adopts ESP32-S3R8 chip with 2.4GHz Wi-Fi and Bluetooth BLE 5 support, 32-bit LX7 dual-core processor, up to 240MHz main frequency, built-in 512KB S-RAM and 384KB ROM, with onboard 16MB Flash and 8MB PSRAM
• ESP32-S3 with 1.64inch AMOLED screen, QSPI interface, 280 × 456 resolution, 16.7M color, 178° wide viewing angle. Supports capacitive touch function, controlled via I2C interface
• Onboard QMI8658 6-axis IMU (3-axis accelerometer and 3-axis gyroscope) for motion gesture detection, step counting, and more
• Onboard RST button, along with programmable BOOT button for customizable functionality and flexible development. Onboard TF card slot, enabling external storage for pictures or files
• Onboard USB Type-C port for power supply, program downloading, and debugging, making development more convenient. Adapting I2C, UART, and USB interfaces, for connecting peripherals and debugging
