Flipsky Dual FSESC6.7 Plus with Anti-Spark Switch Integrated Based on VESC6 Electric 100A 12S ESC Speed Controller for Electric Skateboard

Dual FSESC6.7 Plus(Pro swtich) based on Dual FSESC6 Upgraded features: Pro switch version: Power on/off by pressing the button Added Can bus connector, be more convenient for 4WD set up Changed the USB port soldering process to SMT soldering instead of manual soldering Changed the big capacitors to SMT mounting capacitors ,and add more mosfets in the bottom side. Spec: Hardware: V 6.7 Firmware: Latest firmware version Voltage: 8V - 60V (Safe for 3S to 12S LiPo) for the dual ESC Voltage spikes may not exceed 60V Current: Continuous 100A single, total 200A , Instantaneous current 400A per single, total 800A for system instantaneous current. 5V 1.5A output for external electronics for single 3.3V 1A output for external electronics for single Modes: DC, BLDC, FOC (sinusoidal) Supported sensors: ABI, HALL, AS5047 Size: 78x78x20mm including heatsink Reminder: Detected battery voltage tolerance: +/-0.6V The shipping package contains: 1*Dual FSESC6.7+Heatsink 2*ESC Sensor Wires 1*LED button 1*Micro USB 1*Manual
