GUETNEU LCD Digital Display Time Relay, Dual Time Delay Relay, DPDT 12 VDC with Plug-in Terminal Socket

Additional Details from the Manufacturer

This item information is coming from the manufacturer. Some of the details may vary from the Nellis Auction listing. Please check the Quality Rating and Notes for information specific to this listing

More features

• High-quality Material: Made from premium ABS, it offers excellent electrical insulation, strong durability, and a fire resistance rating of V-2, ensuring safety against flames; The contact pins are made of silver alloy, ensuring strong conductivity
• Flexible & Independent Settings: Users can choose delay mode with “+” and “-” buttons (long press for 3 s, then press “-” ), adjust delay time (press “+” to increase, “-” to decrease; in cyclic mode, long press “-” for 3 s to set T2, adjustable from 0.1 s to 990 h), and select time units (long press “+” for 3 s, then press “+”; in cyclic mode, press “-”); Settings are saved after 8 s of inactivity
• 5 Delay Modes Available: Users can select from the following options: N1 Power-On Delay, N2 Delayed Release, T1T2 Cyclic Delay (triggered on the falling edge), T1T2N2 Cyclic Delay (triggered on both edges), and T1T2N1 Single Cycle Delay
• LCD Dual Time Display: This product features a high-brightness LCD screen for real-time timing, offering clear and accurate readings; The dual time display intuitively shows 2 different time settings, making monitoring and adjustment convenient
• Wide Application Range: Widely used in power systems, home appliance control, and traffic management, etc.; It provides timing control for watering systems, washing machines, and air conditioners, ensuring precision and reliability for everyday life
