Hosyond 4Pack 4 Channel DC 5V Relay Module with Optocoupler Relay Board for Arduino Raspberry Pi MEGA2560

1/2

2/2

Ended

Won For

Search Active Auctions

Description

Module parameters: ▪Size: 71.5mm(L)*52.7mm(W)*18.5(H)mm ▪Single weight: 56g ▪PCB color: blue ▪There are 4 fixing screw holes around the board, the hole diameter is 3.1mm, which is convenient for installation and fixing ▪High quality relays. A common end, a normally open end, and a normally closed end. ▪Optocoupler isolation, good anti-interference. ▪High Level or Low Level Trigger. The status indicator is on when it is engaged, and it is off when it is released. ▪VCC is the system power supply, JD_VCC is the relay power supply. Just plug in the jumper cap. ▪Power supply voltage: 5VDC ▪Current: more than 100mA ▪Load: 250V 10A AC or 30V 10A DC Wiring instructions: VCC: positive pole of system power supply GND: Negative pole of system power supply IN1--IN2: relay control port (Do not reverse the connection to avoid burning out) Packing List: 4 x 4 channel relay module 1 x 10pin F-M Dupont wire

Item Details

Seller

Nellis Auction

Pickup Location

7440 Dean Martin Dr Suite 204

Las Vegas, NV, 89139

Quality

New

Untested

No Damage

Assembly Required

In Package

Unknown if Missing Parts

Estimated Retail Price

$15.99

Buyers Premium

15%

Inventory Number

1052365400

Found in

Electronics Computers, Laptops, Tablets & Accessories

Additional Details from the Manufacturer

This item information is coming from the manufacturer. Some of the details may vary from the Nellis Auction listing. Please check the Quality Rating and Notes for information specific to this listing

brand

Hosyond

size

4 Channel

More features

The power supply voltage of the relay module is DC5V. The maximum output load is AC250V 10A and DC30V 10A.
The relay has a standard interface and can be directly connected to the microcontroller, which is convenient for wiring. Package contains 10pin male to female DuPont wires.
High Level or Low Level Trigger. Pull in at low level and release at high level. The status indicator is on when it is pull in, and it is release when it is released.
The 4 channel relay interface board can directly control Arduino, AVR, PIC, ARM, PLC and other microcomputers, and can also control various high-current electrical appliances and other equipment.
Widely used in all MCU control, industrial fields, PLC control, smart home control.
