Mellanox ConnectX-3 Dual-Port QSFP+ 40GbE Network Card - PCIe 3.0 x8 Enterprise/Data Center NIC with Hardware Offload & RoCE Support

Description PCIe x8 Mellanox Connectx-3 Dual-Port 40G QSFP adapter with PCI Express 3.0 deliver high-bandwidth and industry-leading Ethernet connectivity for performance-driven server and storage applications in Enterprise Data Centers, High-Performance Computing, and Embedded environments. Clustered databases, web infrastructure, and high frequency trading are just a few applications that will achieve significant throughput and latency improvements resulting in faster access, real-time response and more users per server. ConnectX-3 EN improves network performance by increasing available bandwidth while decreasing the associated transport load on the CPU especially in virtualized server environments. Specification PCI-Express host interface specification v3.0 x8 and Complete with PCIe2.0 and 1.1 Two 40 Gigabit QSFP+ Ethernet ports Compliant with QSFP+ MSA Spec Rev 1.0 Two QSFP ports supporting FDR-14 InfiniBand or 40Gb Ethernet Support for InfiniBand FDR speeds of up to 56Gbps (auto-negotiation FDR-10, DDR and SDR) Low-profile form factor adapter with 2u bracket Virtual protocol interconnect (VPI) InfiniBand Architecture specification v1.2.1 compliant IEEE Std. 802.3 compliant Compliant with copper cables and optical cables with the use of QSFP connectors. Support for SFP+ cables available through QSA (Quad to Serial) CORE-Direct application off-load GPUDirect application off-load RDMA over converged Ethernet (RoCE) End-to-End QoS and congestion control TCP/UDP/IP stateless off-load Ethernet encapsulation (EoIB) SR-IOV support;16 virtual functions supported by KVM and Hyper-V(OS dependant ) up to a maximum 127 virtual functions supports by the adapter Enables low latency RDMA over 40GbEthernet (supported with both non-virtualized and SR-IOV enable virtualized servers)—latency as low as 1us Traffic steering across multiple cores Microsoft VMQ/VMware Net Queue support Industry-leading throughput and latency performance Legacy and UEFI PXE network boot support Supports iSCSI as a software iSCSI initiator in NIC mode with NIC driver Supports Operation Systems: FreeBSD, Linux5.x and above, VMware, Windows server2008/2012/2016/2019, win7/win8/win8.1/win10 32 or 64bit Package content 1 x PCIe x8 Mellanox Connectx-3 Dual-Port 40G QSFP adapter 1 x User’s Manual 1 x CD Driver 1 x Low profile bracket
