Motorized 3 Way DC 12V Brass Ball Valve - G1/2 DN15 Thread Connection, Control Switch

Specification: Sealing Material: Special Rubber Driver Base Material: Die-Cast Aluminum Driver Cover Material: Flame Retardant ABS Engineering Plastics Driver Motor: Hysteresis Synchronous Motor Power Consumption: 7.5VA Valve Body Pressure: 1.6Mpa Allowable Pressure: 0.13Mpa Applicable Medium: Cold Water, Hot Water Applicable Medium Temperature: 2-95 Applicable Environment Temperature: 0-60 Open Time: About 10 seconds Close Time: About 5 seconds Valve Connection Mode: G1/2 Weight: Approx. 517g / 18.2oz Height: Approx. 12cm / 4.7in Diameter: Approx. 2cm / 0.8in Package List: 1 x Motorized Ball Valve Installation and Commissioning: 1. Before the installation must carefully read the instructions, cut off the power and must be installed by professionals. 2. direction must be the same as the direction of the arrow on the valve body. 3. The valve body must be located the fan water tray, to ensure that the drip drop into the water tray. 4. Valve body and driver must be installed in the vertical direction ±60° range, it should have at least 30mm space . 5. The building must maintain enough maintenance space, and must be installed in the maintenance that repairing person can reach. 6. Two and more than two of the electric valve can not be parallel, if the need for parallel relays to be separated. Note: Please note that the new type and old type of this product will be sent randomly, and make sure you will not mind before ordering.
