QWinOut XT30 Plug Pigtail Power Wire 100uF Capacitor for Mobula7 HD Sailfly-X TRASHCAN UR85 UR85HD Crazybee F3 / F4 PRO Parts (4 pcs)

Brand: QWINOUT Wire length: 70mm(include xt30) Height: 2.6gram Used for : Crazybee F3 / F4 PRO series flight controller Can avoid the risk of burning the mosfet or the 5v regulator at the moment of power on With this Capacitor , we can use 3S 300~350mah battery for the Crazybee F4 PRO V2.0 and Crazybee F4 PRO V2.1 , and 2s 300~350mah battery for the Crazybee F4 PRO V1.0 And if you want to use the battery above 350mah , we recommend use 220 uF or above capacitor. We found most of the 5v regulator and esc of the Crazybee F4 flight controller burnt after mod the PH2.0 to XT30 . Also, more powerful the battery is(lower esr than stock battery) , more possibility to fail. And, the temporary solution is add a low esr capacitor onto xt30 connector. This capacitor should have a esr less than 0.2 ohm and have a capacitance more than 100uF. Rubycon ZLG/ZLH series and Samyoung NXB series are what we have tested and recommended. Plese refer to our pics: Our pictures show what happened after plug in battery The max voltage is 19v and the voltage spike lasted for about 5us.After add a 100uF/16v (NXB16VB100M5*11_LO) capacitor, we obtained a much slower and smaller spike: Without 100uF, the max spike voltage increase to ~25v while with 100uF it decrease to about 20v, which is acceptable to Crazybee F4 PRO V2.0 and Crazybee F4 PRO V2.1
