Qiilu DC Motor Speed Controller, Brush Motor Driver Controls Module with Throttle Grip DC 12V 24V 36V 48V 500W Aluminium Alloy

Photo 1 of Qiilu DC Motor Speed Controller, Brush Motor Driver Controls Module with Throttle Grip DC 12V 24V 36V 48V 500W Aluminium Alloy
1/2
Photo 1 of Qiilu DC Motor Speed Controller, Brush Motor Driver Controls Module with Throttle Grip DC 12V 24V 36V 48V 500W Aluminium Alloy
2/2

Ended

14 hours

Won For

$2

Search Active Auctions

Description

Specification: Item Type: Motor Brush Speed Controller Material: Aluminium Alloy + Rubber + ABS Rated Voltage: 36V Throttle Control Set: 3 Pin Power Rating: 500W Rated Current: 27±1A Conversion Efficiency: 95% Undervoltage : 31.5±0.5V Working Voltage: 5V Adjustment Range: Minimum 1.0V; Maximum 4.0V Governor: 1-4V (Throttle) Function: High, Medium and Low Speed Governor Plug: 1. Red and Black (large cable): Battery connections 2. Yellow and Blue: Motor connections 3. Red and Blue: Key Switch (power lock) (If there is no power door locks, red is connected to blue) 4. Yellow and black: brake 5. Red and Yellow: Brake light 6. Red and Black(small cable) : indicator light 7. Red, Black and Blue: Speed Regulator 1-4V (Throttle) (Red: +5V, Black: -, Blue: Wire) 8. Red and Black (small cable): Package List: 1 x Motor Brush Speed Controller 2 x Throttle Grip (Left + Right)

Item Details

Pickup Location

4031 Market Center Dr Suite 303

North Las Vegas, NV, 89030

Quality

Used
Functional
No Damage
No Assembly Needed
In Package
No Missing Parts

brand

Qiilu

Estimated Retail Price

$19.99

Buyers Premium

15%

Inventory Number

1046414881

Found in

Outdoors & SportsScooters & Hoverboards

Features

  • Wide Application --- The package contains 2pcs throttle grips and one motor brush speed controller, universal for 12V 24V 36V 48V, motor brushed controller grip kit is suitable for electric scooters bikes motorcycles.
  • Easy To Control --- This is a brushed motor controller, which can provide stable speed and sensitive braking and commutation control, more convenient to control the your electric scooters.
  • High Reliability --- The wire and interface are , ensuring a low malfunction for long term use. There are explanatory labels on the interface for easy installation.
  • Good Heat Dissipation --- The controller shell is made of aluminum alloy material, which can the internal circuit, facilitate heat dissipation, and avoid thermal overload.
  • Stable Performance --- The brushless motor controller is stable, sensitive to the working state of the , with high, medium and low speed governor.
