QitinDasen 5 Pieces 4 Pin Car Relay, 24V 40A SPST Automotive Relay with Harness Socket and 14/16 AWG Pre-Wired, for Car Truck Boat (Black)

Specifications: ◆Material: Plastic + Metal + Copper ◆Size: (L*W*H) Relay Size: 3.1 X 2.7 X 3.7 cm Socket Size: 3.2 X 2.7 X 2.8 cm Pre-Wired Length: 13 cm Pre-Wired Gauge: 14/16 AWG Fixing Hole Diameter: 0.6 cm ◆Weight: 55 g ◆Color: Black ◆Package Includes: 4 Pin Car Relay X 5 Pieces Harness Socket with Pre-Wired X 5 Pieces Metal Mounting Bracket X 5 Pieces 4 pin car relay with harness socket and pre-wired. The automotive relay is an electronic control device, usually used in an automatic control circuit. It is in fact an "automatic switch" that controls a large current through a small current. It has the function of automatic adjustment, safety protection, and conversion circuit. Product Parameters: ◆Contact Material: Ag Alloy ◆Contact Ratings: 24VDC / 40A ◆Contact Resistance: ≤ 50mΩ ◆Electrical Life: More than 100,000 Operations ◆Mechanical Life: More than 10,000,000 Operations ◆Minimum operating voltage 16V, corresponding minimum operating current is 50mA. ◆Standard operating voltage 24V, corresponding standard operating current is 70mA. ◆Coil Power: 1.8W ◆Operate Time: ≤15ms ◆Release Time: ≤10ms ◆Initial withstand voltage of Contact and Contact: 1000VAC / 1Min ◆Initial withstand voltage of Contact and Coil: 1500VAC / 1Min ◆Insulation Resistance: ≥ 100mΩ / 500VDC ◆Temperature Range: 0°C～85°C ◆Humidity Range: 35%～80%
