Radiolink F722 Flight Controller Open Source Betaflight 8 Channels FC, Built-in OSD, Support DJI & CADDX HD and Analog FPV Image Transmission, SBUS/CRSF Support for Racing Drone, Quadcopter

Features

• 【High Configuration】F722, equipped with a STM32F722RET6 main processor, ICM42688 gyroscope, BMP280/DPS310, 128MB capacity of Black Box, and MP2491C switching power supply chip from MPS. It supports BETAFLIGHT and INAV firmware.
• 【DJI/CADDX HD Digital Video Transmission Plug-and-play】It supports DJI and CADDX high-definition digital image transmission plug-and-play.
• 【Built-in Multiple BEC】The BEC can selectable voltages (3.3V/4.5V/5V/12V) via a switch, and supports toggling image transmission power. It also allows to modify the power frequency transmission through the transmitter and goggles.
• 【Variety Function Supported】Support current various mainstream throttle signals, like two-way DShot, OneShot, and PWM signals. ESC information telemetry supports.
• 【OSD Module Integrated】F722 can graphically display OSD information such as flight mode, distance, GPS sats, longitude and latitude, home direction, GPS speed, and battery voltage. The pilot can get more information during the FPV (first-person view) flight.
• 【Multiple Interfaces】Supports up to 8 channels output and is adaptable to a 2-8 axis multi-rotor including X8 models. A combination of socket interface and solder pad makes it more convenient to connect external devices.
