SSR-40AA Solid State Relay AC to AC (Input 80-250V AC Output 24-380V AC) with Heat Sink, 40A

DMWD Low cost single phase solid state relay SSR-40AA Input voltage 80-250V AC Load voltage 24-380V AC Load current 40Amp 40A 80-250V AC to AC solid state relay (SSR) features high structural strength, good impact resistance, and strong shock resistance. The SSR offers a reliable switching the commercial and industrial loads, such as computer peripheral interface device, printing machine, molding machine, food machine, packaging machine, and so on. Built in RC absorption Photoelectric isolation SCR output LED indicator for operation status Panel mount Zero-crossing switch type UL Approved, CE Compliant to EN60950-1 Note: * When the load current is higher than 10A, a heat sink must be installed to the solid state relay, or the SSR relay should be mounted on a metal base plate with heat dissipation effect, and the thermal grease is applied between them. * When the load current is 40A or more, a fan cooling radiator or water cooling radiator must be equipped. * Heat sink is included. Package Content: 1 x Solid State Relay 1 x All Aluminium Heat Sink Size/Weight: SSR(60x45x23mm/95g) Heat Sink(78*50*50mm/80g) Warranty: Free new replacement in 5 years, Have faith in quality
