STATOR MAGNETO APOLLO DIRT BIKE 50CC, 70CC, 90CC, 110CC, 125CC

Chinese Stator Magneto - 2 Coil - 5 Wire for Apollo Dirt Bike Pit Bike DB 007 DB X5 X7 X18 50cc-125cc Fits Chinese 50cc-125cc Apollo Dirt Bikes. BRAND NEW - Charging Magneto Stator This is a 2 Pole Stator Magneto Generator found on the 4 stroke, 150cc chinese made engines Please make sure your unit is not using a 6 pole stator Check out the detailed pictures to see if this will fit your vehicle!!! SPECS: Outside Diameter: 115mm Inside Diameter: 18mm Width: 47mm at pick up Bolt Hole Spacing: 102mm Bolt Hole Diameter: 7mm Number of Coils: 2 5 wire. Single Male plug includes Pick up Fits: DB-21 70cc (DB25) DB-25 70cc ((DB25) DB-34 110cc (DB34) DB-X4 110cc DB-35 125cc DB-99 125cc (DB99) DB-007 125cc (DB 007) DB-X5 125cc (DB-X5) DB-X7 125cc (DB-X7) DB-X18 125cc Some 007 Dirt Bikes may contain a 6 pole stator. Please check you stator to ensure it is the same as pictured above. Our high quality stator magnetos are the exact replacement part for many Chinese manufactured brands and models of Chinese Scooters. This Chinese Stator magneto fits many models and makes of Chinese Go Karts and Scooters
