STPCTOU 8AN Male Flare to 10AN ORB O-ring Boss Fuel Pump Rail Fitting Adapter Aluminum Alloy Connector Black Anodized

Additional Details from the Manufacturer

This item information is coming from the manufacturer. Some of the details may vary from the Nellis Auction listing. Please check the Quality Rating and Notes for information specific to this listing

More features

• 🚗DURABLE MATERIAL:The 8AN to 10AN ORB fittings are made of lightweight 6061-T6 aluminum alloy for high strength. The surface is black anodized and hand-polished, making the product aesthetically pleasing, corrosion-resistant, with high thread strength and durability.The O-ring is made of nitrile rubber, which has excellent oil and heat resistance, contributing to a better seal. Reusable and recyclable .(Parameter: Working pressure: 1500PSI. Working temperature：-65°F-252°F. )
• 🚗PERFECT DESIGN:The 8AN to 10AN ORB Adapter Fitting seals the female port with a male fitting with an O-ring that has an angled portion with an O-ring in place.The O-ring flange adapter has straight threads so it will not damage the mating parts. The fitting seals with an O-ring and the only thing required is a small amount of lubricant, petroleum jelly, or some type of petroleum product (such as motor oil) applied to the O-ring. This design makes the fitting repeatable for long term use.
• 🚗EASY TO INSTALL:8AN to 10AN ORB, the thread size of 8AN is 3/4-16 UNF, and the thread size of 10AN ORB is 7/8-14 UNF.The side of AN is a 37 degree angle taper flare fitting and the ORB side is an O-ring.To install a straight-through 8AN-8AN ORB fitting, screw the fitting into the mating part until the preformed packing is completely in the mating packing seat. Tighten the fitting until snug. Check the ORB fitting for leaks when the system is started. If leaking, retighten tubing or hose.
• 🚗WIDE APPLICATION: 10AN ORB to 8AN flare converter is widely used in oil coolers, oil tanks, fuel pumps and fluid lines to connect female fittings. Flare fittings can be used in a wide range of applications such as water, air, fuel, oil, fluids, E85 and more. The flare is designed with a 37 degree angle seal on the AN side and an O-ring seal on the ORB side to ensure leak-free performance.
• 🚗STPCTOU BRAND QUALITY ASSURANCE:We provide 12-Month Warranty for any quality issues. If you're not 100% completely satisfied with your 8AN Flare to 10AN O-ring ORB Male Fuel Pump Rail Adaptor Fittings, just simply contact us and we will refund or replace your product immediately. Please contact us first if you have any question about our products, our support team will try our best to help you solve all the issues. Email reply within 24hs.
