Taidacent Universal LVDS Controller Board 10-65 Inch LCD Screen HDMI DVI VGA to LVDS Driver Board DIY Notebook Display Kit (18.5-27 inch 1080P Universal 8 kit)

CHIPSET:NT68676（UFG） MARKET AREA :Asia-Pacific OSD LANGUAGE：Simplified chinese，Tradtional chIese，English，French，German，Italian，Spanish，Portuguese，Japanese，Korean（optional） PANEL Panel Type :LED/LCD Panel Interface:Single/Dual LVDS（8bit） Max Resolution:2048×1152 PC-RGB:Format up to 2048×1152@60Hz HDMI :480i，480P，576i ,576p,720p 1080i,1080p AUDIO INPUT PC Audio : Earphone input 0.2~2.0 AUDIO OUTPUT Frequency Responses :100Hz～15KHz @±3dB(1KHz, OdB reference signal) Max Output power:2x1W(8Ω) THD+N<10%@1KHz (Power Supply:12V, Audio Input:0.5V) POWER Requirement:12V DC/12V(built)/12V,5V(built in)/12V,5V,5VSB(built in) To Panel:3.3V/5V/12V Management:Standby Power Consumption<0.5W(Board Only) KEY FUNCTION :POWER, MENU, VOL+, VOL-, ADJUST/EXIT
