Toggle Anchor Bolts, Hollow Wall Anchors 304 Stainless Steel Scissors Type Heavy Duty X Anchor M8x110mm, Pack of 4

Specification: Diameter of screw stem : 8mm Diameter of scissors head: 16mm Length of screw stem: 70mm Length of scissors head: 54mm Overall length: 110mm Tensile strength: 1.2tons Shear force: 1.5tons Package Content: 4pcs M8*110mm toggle anchor bolts Installation method: 1. Punch a hole according to the size. If possible make hole incline upwards 5 to 10 degrees. Item M8x110mm hollow wall anchors need drill punch a hole at diameter 16mm; depth at 85mm or according to the installed object. 2. Ensure 2pcs X type plates acrossed and back, and the cup head of the screw stem need between 2pcs plates. 3. Hold the toggle anchor and put it into the hole. Rotate the screw stem clockwise then the plates will expand untill feel fasteness enough. Take down the flat washer, spring washer and the nut then install object. Finally, get back flat washer and spring washer in turn and then tighten the nut.
