VictorsHome Changeover Switch LW28-63 3 Positions 12 Terminals Universal Rotary Cam Selector Latching Switches 690V 63A

Description 1.Suitable for the thickness between 1mm to 5mm of the mounting board. 2.Ideal choice for electrical wiring in the power switches, speed switches and asynchronous motor for their start-up and reversing, also can make the conversion of the control circuit. 3.Widely used as circuit control switches, test equipment switches, motor control switches and master control switches, signal transfer switches, or change-over switch for electric welding machinery and other equipment. Image3 has shown which terminal will be connected in different position , please read the wiring diagram as a reference. Position 1 : 1-2 , 5-6 , 9-10 Position 0 : All terminal disconnected Position 2 : 3-4 , 7-8 , 11-12 Specifications Model: LW28-63/3 Positions: 3 Terminals: 12 Ui: 690V Ith: 32A Action Type: Latching Positioning angle: 60-0-60 Degree Rating: DC-13: Ui: 220V, Ith: 0.14A; AC-15: Ue / Ie: 380V / 1.5A Mounting Hole Distance: 48mm x 48mm / 1.89inch x 1.89inch (L*W) Total Size: 65mm x 65mm x 132mm / 2.56inch x 2.56inch x 5.2inch (L*W*H) Package Content 1 x Changeover Switch 4 x Mounting Screws
