WAOUKS 84V 3A Charger 84V Li-ion Battery Charger with Cooling Fan Red Aluminum Case Used for 20S 72V 74V Lithium Battery Pack,84V Smart Charger DC Output 3pin C13 Ping Connector

Specification: Product Name: 84V 3A Battery Charger Model: WA240-8403RED Dimensions: 170x90x50mm Color/Material: Red/Aluminum Case Suitable for Battery type: 20S 72V Li-ion Battery AC Input: 100-120Vac, 60Hz Output Voltage: 84 Volt Output Current: 3 Amp Battery Protection: SCP,OVP,OCP,OTP Charging Mode: Constant current - Constant Voltage - Trickle : Three-stage Intelligent Charging Charging Efficiency: ≥85% Working temperature: -5 ℃ ~ +40 ℃ Storage temperature: -40 ℃ ~ +70 ℃ AC power cord, DC connector can be customized. Operating Instruction 1. Before charging, please connect the DC terminal to battery first, and then connect the AC terminal. 2. After charging complete, unplug the AC terminal firstly, and then unplug the DC terminal. 3. No charging or after charging complete, be sure to unplug the DC terminal and AC terminal. LED Indicator: LED 1 Red: Power on. LED 2 Red: Battery being charged. LED 2 Flash: Battery will be charged completely soon. LED 2 Green: Battery has been charged completely. Package: 1* 84V 3A charger 1* US standard power cable 1* Operating manual 2* Fuse for replacing
