XANHAM 30 Pack Cat7 Cat6A Pass Through Shielded RJ45 Connector Modular Network 50? Gold-Plated Plug for Cat 6, Cat 6A, Cat 7 and Cat 8 with Strain Relief Boots

Features

• Shielded RJ45 Standard: Connector terminates shielded twisted pair cable for making a custom-length Cat 6A, Cat7 or Cat 8 Ethernet cable with 22-23AWG round stranded and solid wire, backward support Cat6 Ethernet cable for insulated conductors diameter from 1.04 to 1.4mm.
• Pass Through Style with Load Bar: Load bar can help to identify wire sequences before crimping. Since the wires are inserted through the connector and out the other side with the pass-through style, the length of the wires can be cut off more flexibly when you feed the wire into the load bar.
• Three Prong 50μ Gold Plated Contact: High quality contacts can increase the contact area and enhance conductivity. Supporting Cat8 40 Gigabit Ethernet channel for wired Ethernet or PoE application, backwards compatible with Cat7, Cat6A and Cat6 cables.
• Nickel Plated Copper Shell: Upgrade copper case connect to the ground wire helping to reduce electrostatic interference and improve connection stability. The copper shell also improves the durability of the connector.
• Strain Relif Boot: Package include 30*RJ45 connector, 30*load bar and 30*Black Strain Relif Boot. The boots support cable overall diameter up to 8.0mm.
• TIPS: Even though the connector have the buckle to connect the ground wire for shielded cable, we suggest to use copper foil tape to wrap the ground wire for helping the connector connect to the ground wire more stably.
