uxcell AXK120155 Needle Roller Thrust Bearings with 2 Washers, 120mm Inner Diameter, 155mm OD 4mm Width Chrome Steel

Description: This Needle Roller Thrust Bearings provide a high degree of stiffness within a minimum axial space. It has a smaller cross-section than a standard thrust bearing for use in restricted spaces. These bearings to accommodate heavy axial loads and peak loads due to the small diameter deviation of the rollers within one assembly. AXK Thrust Bearings can be combined with washers in the AS series in applications where adjacent components cannot serve as raceways. Made of hardened spring steel, both faces of the washers are polished and can be used as raceways. Rolling bearings are used in a range of applications from agricultural machinery to conveying equipment, robotics, elevators, rolling mills, ship rudder shafts, ect. Specification: Bearing Model: AXK120155 Bearing Washer Model: AS120155 Needle Roller Meterial: Chromium Steel (GCr15) Cage Meterial: ST13 Steel Bearing Washer Meterial: 65Mn Spring Steel Inner Diameter : 120mm Outside Diameter (D): 155mm Bearing Rollers Diameter: 4mm Total Thickness(with Washers): 6mm Dynamic Load Capacity (Cr): 680kN Static Load Capacity (Cor): 102kN Maximum Rotational Speed (Oil): 2070rpm Package Content: 1 x Bearing 2 x Washers
